SALIENT FEATURES :
• Complete filtration of the batch without any hold up due to reverse flow of liquid hence large saving in time & cost.
• Back wash facility can be provided for continuous operations.
• No scavenger arrangement required.
• The cake, filteraid & solids remain totally enclosed allowing filtration of toxic, hazardous & explosive liquids.
• No contamination of internal surface of shell.
• The top dome structure ensures fast & easy removal of cartridge assembly & cleaning of cake.
• Other features same as standard flow type.
| Model | Dai. of Plate | No. of Plates | Filtering Area (m ) | Cake Holding Capacity | Flow Rate LTRS / HRS. |
Size of Pump | Motor HP |
| BPZH-8 | 8" | 6 8 |
0.217 0.279 |
4.5 5.5 |
600 800 |
0.5" 0.5" |
1 HP 1 HP |
| BPZH-14 | 14" | 8 10 12 |
0.819 1.001 1.183 |
22.5 27.5 32.5 |
1500 1700 1900 |
1" 1" 1" |
2 HP 2 HP 2 HP |
| BPZH-18 | 18" | 10 12 15 24 |
1.65 1.95 2.40 3.75 |
44 52 64 100 |
4000 4600 5500 8200 |
1.5" 1.5" 1.5" 1.5" |
3 HP 3 HP 3 HP 3 HP |
| BPZH-24 | 24" | 15 18 24 |
4.192 5.035 6.625 |
136 162 213 |
7000 8500 12500 |
2" 2" 2" |
5 HP 5 HP 5 HP |
| BPZH-33 | 33" | 7 10 14 22 |
4.176 5.736 7.821 12.5 |
118 163 222 345 |
7000 10000 13500 20000 |
2.5" 2.5" 2.5" 2.5" |
5 HP 5 HP 5 HP 5 HP |
Due to constant up gradation in design and manufacturing all dimension & specification are subject to charge and alteration without prior notice.
